WD546 Cast Alloy Wheel
WD546 is a cast alloy wheel (rim) in 1 finish: Gloss Black (Full Paint). It is an OEM-fit replacement, made to the size, bolt pattern, offset and center bore of the original wheel. It comes in 21 inch: 1 size (21x8.5), 1 bolt pattern (5x114.3), offset ET 45 mm and center bore 66.4 mm. Listed for Great Wall (VV7). Not sure what PCD, ET and CB mean? Read how to choose wheels.
Finish
Wheel sizes: 21x8.5
Bolt patterns (PCD): 5x114.3
| Size (D x J) | Offset (ET) | Bolt pattern (PCD) | Center bore (CB) | Hole type | Fits | Stock | Copy specs |
|---|---|---|---|---|---|---|---|
| 21x8.5 | 45 | 5x114.3 | 66.4 | Cone seat | Great Wall VV7 | 50+ |
What these numbers mean
- Size (D x J)
- Diameter in inches, then rim width in inches: 21x8.5 is a 21 inch wheel with a 8.5 inch wide rim. The J after a width, as in 8.5J, names the rim flange profile.
- Offset (ET)
- The distance in mm from the wheel's centerline to its mounting face. WD546 comes in ET 45; a lower ET sits the wheel further out.
- Bolt pattern (PCD)
- The number of bolts and the diameter in mm of the circle they sit on: 5x114.3 is 5 bolts on a 114.3 mm circle. It must match the vehicle.
- Center bore (CB)
- The central hole that sits over the vehicle's hub: 66.4 mm for WD546. A bore larger than the hub needs centering rings.
