WD165 Cast Alloy Wheel
WD165 is a cast alloy wheel (rim) in 7 finishes. It is an aftermarket design. It comes in 15–20 inch: 6 sizes (15x7, 15x8, 16x7, 17x7.5, 18x8.5, 20x9), 8 bolt patterns (5x114.3, 5x112, 4x100, 5x100, 5x108, 6x139.7, 5x120 and 5x127), offset ET -12–35 mm and center bore 66.45–110.1 mm. Feature: anti-slip groove. Not sure what PCD, ET and CB mean? Read how to choose wheels.
Finish
White (Full Paint)High-Gloss Black Machined LipGloss Black Machined LipMatte Black (Full Paint)Hyper Black (Full Paint)Gloss Black (Full Paint)Matte Black + Milled Rivet Holes
Wheel sizes: 15x7, 17x7.5, 18x8.5
Bolt patterns (PCD): 4x100, 5x100, 5x112, 5x114.3
| Size (D x J) | Offset (ET) | Bolt pattern (PCD) | Center bore (CB) | Hole type | Fits | Stock | Copy specs |
|---|---|---|---|---|---|---|---|
| 15x7 | 35 | 4x100 | 67.1 | 14 | |||
| 15x7 | 35 | 5x100 | 73.1 | 50 | |||
| 17x7.5 | 35 | 5x112 | 66.45 | 26 | |||
| 17x7.5 | 35 | 5x114.3 | 73.1 | 12 | |||
| 18x8.5 | 35 | 5x112 | 66.45 | 3 | |||
| 18x8.5 | 35 | 5x114.3 | 73.1 | 12 |
What these numbers mean
- Size (D x J)
- Diameter in inches, then rim width in inches: 15x7 is a 15 inch wheel with a 7 inch wide rim. The J after a width, as in 7J, names the rim flange profile.
- Offset (ET)
- The distance in mm from the wheel's centerline to its mounting face. WD165 comes in ET -12–35; a lower ET sits the wheel further out.
- Bolt pattern (PCD)
- The number of bolts and the diameter in mm of the circle they sit on: 5x114.3 is 5 bolts on a 114.3 mm circle. It must match the vehicle.
- Center bore (CB)
- The central hole that sits over the vehicle's hub: 66.45–110.1 mm for WD165. A bore larger than the hub needs centering rings.
