WD165 Cast Alloy Wheel in High-Gloss Black Machined Lip
WD165 is a cast alloy wheel (rim) in High-Gloss Black Machined Lip, one of 7 finishes. It is an aftermarket design. It comes in 15–18 inch: 4 sizes (15x7, 16x7, 17x7.5, 18x8.5), 6 bolt patterns (5x114.3, 5x108, 4x100, 5x100, 5x112 and 5x120), offset ET 35 mm and center bore 66.45–73.1 mm. Not sure what PCD, ET and CB mean? Read how to choose wheels.
Finish
White (Full Paint)High-Gloss Black Machined LipGloss Black Machined LipMatte Black (Full Paint)Hyper Black (Full Paint)Gloss Black (Full Paint)Matte Black + Milled Rivet Holes
Wheel sizes: 15x7, 16x7, 17x7.5, 18x8.5
Bolt patterns (PCD): 4x100, 5x100, 5x114.3, 5x108, 5x112, 5x120
| Size (D x J) | Offset (ET) | Bolt pattern (PCD) | Center bore (CB) | Hole type | Fits | Stock | Copy specs |
|---|---|---|---|---|---|---|---|
| 15x7 | 35 | 4x100 | 67.1 | 2 | |||
| 15x7 | 35 | 5x100 | 73.1 | 48 | |||
| 15x7 | 35 | 5x114.3 | 73.1 | 50+ | |||
| 16x7 | 35 | 4x100 | 67.1 | 8 | |||
| 16x7 | 35 | 5x100 | 73.1 | 37 | |||
| 16x7 | 35 | 5x108 | 73.1 | 1 | |||
| 16x7 | 35 | 5x112 | 66.45 | 50+ | |||
| 16x7 | 35 | 5x114.3 | 73.1 | 50+ | |||
| 17x7.5 | 35 | 5x108 | 73.1 | 42 | |||
| 17x7.5 | 35 | 5x112 | 66.45 | 12 | |||
| 17x7.5 | 35 | 5x114.3 | 73.1 | 3 | |||
| 17x7.5 | 35 | 5x120 | 72.56 | 17 | |||
| 18x8.5 | 35 | 5x108 | 73.1 | 16 | |||
| 18x8.5 | 35 | 5x114.3 | 73.1 | 1 |
What these numbers mean
- Size (D x J)
- Diameter in inches, then rim width in inches: 15x7 is a 15 inch wheel with a 7 inch wide rim. The J after a width, as in 7J, names the rim flange profile.
- Offset (ET)
- The distance in mm from the wheel's centerline to its mounting face. WD165 comes in ET 35; a lower ET sits the wheel further out.
- Bolt pattern (PCD)
- The number of bolts and the diameter in mm of the circle they sit on: 5x114.3 is 5 bolts on a 114.3 mm circle. It must match the vehicle.
- Center bore (CB)
- The central hole that sits over the vehicle's hub: 66.45–73.1 mm for WD165. A bore larger than the hub needs centering rings.
