WD127 Cast Alloy Wheel in High-Gloss Black Machined Lip
WD127 is a cast alloy wheel (rim) in High-Gloss Black Machined Lip, one of 5 finishes. It is an aftermarket design. It comes in 18 inch: 1 size (18x8.5), 2 bolt patterns (5x112 and 5x114.3), offset ET 35–38 mm and center bore 66.45–73.1 mm. Not sure what PCD, ET and CB mean? Read how to choose wheels.
Finish
Matte Black (Full Paint)Candy Red + Matte Black LipBronze + Matte Black LipHigh-Gloss Black Machined LipGunmetal Machined Lip
Wheel sizes: 18x8.5
Bolt patterns (PCD): 5x112, 5x114.3
| Size (D x J) | Offset (ET) | Bolt pattern (PCD) | Center bore (CB) | Hole type | Fits | Stock | Copy specs |
|---|---|---|---|---|---|---|---|
| 18x8.5 | 35 | 5x112 | 66.45 | 2 | |||
| 18x8.5 | 35 | 5x112 | 66.45 | 21 | |||
| 18x8.5 | 38 | 5x114.3 | 73.1 | 15 |
What these numbers mean
- Size (D x J)
- Diameter in inches, then rim width in inches: 18x8.5 is a 18 inch wheel with a 8.5 inch wide rim. The J after a width, as in 8.5J, names the rim flange profile.
- Offset (ET)
- The distance in mm from the wheel's centerline to its mounting face. WD127 comes in ET 35–38; a lower ET sits the wheel further out.
- Bolt pattern (PCD)
- The number of bolts and the diameter in mm of the circle they sit on: 5x112 is 5 bolts on a 112 mm circle. It must match the vehicle.
- Center bore (CB)
- The central hole that sits over the vehicle's hub: 66.45–73.1 mm for WD127. A bore larger than the hub needs centering rings.
