WD0391 Forged Alloy Wheel in Polished + Brushed Rim
WD0391 is a forged alloy wheel (rim) in Polished + Brushed Rim, one of 6 finishes. It is an OEM-fit replacement, made to the size, bolt pattern, offset and center bore of the original wheel. It comes in 20–22 inch: 4 sizes (20x8.5, 20x9.5, 21x9, 22x9.5), 4 bolt patterns (5x120, 5x112, 5x114.3 and 5x108), offset ET 30–38 mm and center bore 62.5–73.1 mm. Not sure what PCD, ET and CB mean? Read how to choose wheels.
Finish
Gloss Black (Full Paint)PolishedPolished + Brushed RimMatte BronzeMatte Gunmetal (Full Paint)Matte Black (Full Paint)
Wheel sizes: 20x8.5, 20x9.5, 21x9, 22x9.5
Bolt patterns (PCD): 5x112, 5x120, 5x114.3, 5x108
| Size (D x J) | Offset (ET) | Bolt pattern (PCD) | Center bore (CB) | Lug hole (mm) | Load (kg) | Weight (kg) | Stock | Copy specs |
|---|---|---|---|---|---|---|---|---|
| 20x8.5 | 30 | 5x112 | 66.45 | 0 | ||||
| 20x8.5 | 35 | 5x120 | 62.5 | 8 | ||||
| 20x8.5 | 38 | 5x114.3 | 73.1 | 2 | ||||
| 20x9.5 | 35 | 5x112 | 66.45 | 0 | ||||
| 20x9.5 | 38 | 5x114.3 | 73.1 | 6 | ||||
| 21x9 | 35 | 5x108 | 63.4 | 0 | ||||
| 21x9 | 38 | 5x120 | 72.56 | 4 | ||||
| 22x9.5 | 38 | 5x120 | 72.56 | 4 |
What these numbers mean
- Size (D x J)
- Diameter in inches, then rim width in inches: 20x8.5 is a 20 inch wheel with a 8.5 inch wide rim. The J after a width, as in 8.5J, names the rim flange profile.
- Offset (ET)
- The distance in mm from the wheel's centerline to its mounting face. WD0391 comes in ET 30–38; a lower ET sits the wheel further out.
- Bolt pattern (PCD)
- The number of bolts and the diameter in mm of the circle they sit on: 5x120 is 5 bolts on a 120 mm circle. It must match the vehicle.
- Center bore (CB)
- The central hole that sits over the vehicle's hub: 62.5–73.1 mm for WD0391. A bore larger than the hub needs centering rings.
