JX0557 Forged Alloy Wheel
JX0557 is a forged alloy wheel (rim) in 2 finishes: Brushed Aluminium (Natural) and Brushed Transparent Black. It is an aftermarket design. It comes in 19–22 inch: 6 sizes (19x8.5, 19x9.5, 20x8.5, 20x9.5, 22x9.5, 22x10.5), 4 bolt patterns (5x112, 5x120, 5x108 and 5x114.3), offset ET 30–40 mm and center bore 2–73.1 mm. Not sure what PCD, ET and CB mean? Read how to choose wheels.
Finish
Wheel sizes: 19x8.5, 19x9.5, 20x8.5, 20x9.5
Bolt patterns (PCD): 5x112, 5x120, 5x108, 5x114.3
| Size (D x J) | Offset (ET) | Bolt pattern (PCD) | Center bore (CB) | Stock | Copy specs |
|---|---|---|---|---|---|
| 19x8.5 | 30 | 5x112 | 66.45 | 8 | |
| 19x8.5 | 30 | 5x120 | 72.56 | 2 | |
| 19x8.5 | 35 | 5x108 | 73.1 | ||
| 19x8.5 | 38 | 5x114.3 | 73.1 | 0 | |
| 19x9.5 | 35 | 5x112 | 66.45 | 8 | |
| 19x9.5 | 35 | 5x120 | 72.56 | 6 | |
| 20x8.5 | 30 | 5x120 | 72.56 | 10 | |
| 20x8.5 | 35 | 5x108 | 73.1 | 8 | |
| 20x8.5 | 35 | 5x114.3 | 73.1 | ||
| 20x9.5 | 35 | 5x120 | 72.56 | 6 |
What these numbers mean
- Size (D x J)
- Diameter in inches, then rim width in inches: 19x8.5 is a 19 inch wheel with a 8.5 inch wide rim. The J after a width, as in 8.5J, names the rim flange profile.
- Offset (ET)
- The distance in mm from the wheel's centerline to its mounting face. JX0557 comes in ET 30–40; a lower ET sits the wheel further out.
- Bolt pattern (PCD)
- The number of bolts and the diameter in mm of the circle they sit on: 5x112 is 5 bolts on a 112 mm circle. It must match the vehicle.
- Center bore (CB)
- The central hole that sits over the vehicle's hub: 2–73.1 mm for JX0557. A bore larger than the hub needs centering rings.
