WD266 Cast Alloy Wheel
WD266 is a cast alloy wheel (rim) in 2 finishes: Gloss Black (Full Paint) and Gloss Black Machined Face. It is an OEM-fit replacement, made to the size, bolt pattern, offset and center bore of the original wheel. It comes in 16–22 inch: 7 sizes (16x8, 18x8, 20x8.5, 20x9.5, 20x10, 22x9.5 and more), 2 bolt patterns (5x112 and 5x165.1), offset ET 10–40 mm and center bore 66.56–114.3 mm. Listed for BMW. Not sure what PCD, ET and CB mean? Read how to choose wheels.
More wheels for BMW.
Finish
Wheel sizes: 16x8, 18x8
Bolt patterns (PCD): 5x165.1
| Size (D x J) | Offset (ET) | Bolt pattern (PCD) | Center bore (CB) | Hole type | Fits | Stock | Copy specs |
|---|---|---|---|---|---|---|---|
| 16x8 | 10 | 5x165.1 | 114.3 | Flat seat | 0 | ||
| 18x8 | 10 | 5x165.1 | 114.3 | Flat seat | 23 |
What these numbers mean
- Size (D x J)
- Diameter in inches, then rim width in inches: 16x8 is a 16 inch wheel with a 8 inch wide rim. The J after a width, as in 8J, names the rim flange profile.
- Offset (ET)
- The distance in mm from the wheel's centerline to its mounting face. WD266 comes in ET 10–40; a lower ET sits the wheel further out.
- Bolt pattern (PCD)
- The number of bolts and the diameter in mm of the circle they sit on: 5x112 is 5 bolts on a 112 mm circle. It must match the vehicle.
- Center bore (CB)
- The central hole that sits over the vehicle's hub: 66.56–114.3 mm for WD266. A bore larger than the hub needs centering rings.
Fits the same bolt pattern and size
Same PCD, wheel diameter and a compatible center bore.
Similar finish and range
Same collection, with a matching finish or vehicle brand.
Similar design
Wheels that look alike, from the same collection. Check the bolt pattern before you order.
