REW007 Cast Alloy Wheel
REW007 is a cast alloy wheel (rim) in 1 finish: Matte Black (Full Paint). It is an aftermarket design. It comes in 16 inch: 1 size (16x7), 3 bolt patterns (4x100, 5x100 and 5x108), offset ET 35 mm and center bore 57.1–73.1 mm. Not sure what PCD, ET and CB mean? Read how to choose wheels.
Finish
Wheel sizes: 16x7
Bolt patterns (PCD): 4x100, 5x100, 5x108
| Size (D x J) | Offset (ET) | Bolt pattern (PCD) | Center bore (CB) | Stock | Copy specs |
|---|---|---|---|---|---|
| 16x7 | 35 | 4x100 | 67.1 | 1 | |
| 16x7 | 35 | 5x100 | 57.1 | 5 | |
| 16x7 | 35 | 5x108 | 73.1 | 50+ |
What these numbers mean
- Size (D x J)
- Diameter in inches, then rim width in inches: 16x7 is a 16 inch wheel with a 7 inch wide rim. The J after a width, as in 7J, names the rim flange profile.
- Offset (ET)
- The distance in mm from the wheel's centerline to its mounting face. REW007 comes in ET 35; a lower ET sits the wheel further out.
- Bolt pattern (PCD)
- The number of bolts and the diameter in mm of the circle they sit on: 4x100 is 4 bolts on a 100 mm circle. It must match the vehicle.
- Center bore (CB)
- The central hole that sits over the vehicle's hub: 57.1–73.1 mm for REW007. A bore larger than the hub needs centering rings.
