7116 Cast Alloy Wheel
7116 is a cast alloy wheel (rim) in 1 finish: Gunmetal Machined Face. It is an OEM-fit replacement, made to the size, bolt pattern, offset and center bore of the original wheel. It comes in 17 inch: 1 size (17x6.5), 1 bolt pattern (5x108), offset ET 43 mm and center bore 65.1 mm. Listed for Dongfeng Aeolus. Not sure what PCD, ET and CB mean? Read how to choose wheels.
Finish
Wheel sizes: 17x6.5
Bolt patterns (PCD): 5x108
| Size (D x J) | Offset (ET) | Bolt pattern (PCD) | Center bore (CB) | Hole type | Fits | Stock | Copy specs |
|---|---|---|---|---|---|---|---|
| 17x6.5 | 43 | 5x108 | 65.1 | Cone seat | Dongfeng Aeolus | 0 |
What these numbers mean
- Size (D x J)
- Diameter in inches, then rim width in inches: 17x6.5 is a 17 inch wheel with a 6.5 inch wide rim. The J after a width, as in 6.5J, names the rim flange profile.
- Offset (ET)
- The distance in mm from the wheel's centerline to its mounting face. 7116 comes in ET 43; a lower ET sits the wheel further out.
- Bolt pattern (PCD)
- The number of bolts and the diameter in mm of the circle they sit on: 5x108 is 5 bolts on a 108 mm circle. It must match the vehicle.
- Center bore (CB)
- The central hole that sits over the vehicle's hub: 65.1 mm for 7116. A bore larger than the hub needs centering rings.
