WD0500 Forged Alloy Wheel in Gloss Black Machined Face
WD0500 is a forged alloy wheel (rim) in Gloss Black Machined Face, one of 3 finishes. It is an OEM-fit replacement, made to the size, bolt pattern, offset and center bore of the original wheel. It comes in 21–22 inch: 5 sizes (21x8.5, 21x9, 21x9.5, 22x8.5, 22x9.5), 2 bolt patterns (5x112 and 5x120), offset ET 25–38 mm and center bore 62.5–66.5 mm. Not sure what PCD, ET and CB mean? Read how to choose wheels.
Finish
Wheel sizes: 21x8.5, 21x9, 21x9.5, 22x8.5, 22x9.5
Bolt patterns (PCD): 5x112, 5x120
| Size (D x J) | Offset (ET) | Bolt pattern (PCD) | Center bore (CB) | Load (kg) | Weight (kg) | Stock | Copy specs |
|---|---|---|---|---|---|---|---|
| 21x8.5 | 25 | 5x112 | 66.5 | 950 | 18 | 2 | |
| 21x9 | 38 | 5x120 | 62.5 | 8 | |||
| 21x9.5 | 33 | 5x112 | 66.5 | 950 | 18.2 | 4 | |
| 22x8.5 | 35 | 5x112 | 66.5 | 12 | |||
| 22x9.5 | 33 | 5x112 | 66.5 | 0 | |||
| 22x9.5 | 35 | 5x112 | 66.5 | 12 |
What these numbers mean
- Size (D x J)
- Diameter in inches, then rim width in inches: 21x8.5 is a 21 inch wheel with a 8.5 inch wide rim. The J after a width, as in 8.5J, names the rim flange profile.
- Offset (ET)
- The distance in mm from the wheel's centerline to its mounting face. WD0500 comes in ET 25–38; a lower ET sits the wheel further out.
- Bolt pattern (PCD)
- The number of bolts and the diameter in mm of the circle they sit on: 5x112 is 5 bolts on a 112 mm circle. It must match the vehicle.
- Center bore (CB)
- The central hole that sits over the vehicle's hub: 62.5–66.5 mm for WD0500. A bore larger than the hub needs centering rings.
