WD0263 Forged Alloy Wheel
WD0263 is a forged alloy wheel (rim) in 1 finish: Gloss Black Machined Face. It is an OEM-fit replacement, made to the size, bolt pattern, offset and center bore of the original wheel. It comes in 20–22 inch: 3 sizes (20x8.5, 21x9, 22x9), 1 bolt pattern (6x139.7), offset ET 30 mm and center bore 78.1 mm. Listed for Nissan (Patrol). Not sure what PCD, ET and CB mean? Read how to choose wheels.
More wheels for Nissan.
Finish
Wheel sizes: 20x8.5, 21x9, 22x9
Bolt patterns (PCD): 6x139.7
| Size (D x J) | Offset (ET) | Bolt pattern (PCD) | Center bore (CB) | Lug hole (mm) | Load (kg) | Weight (kg) | Fits | Stock | Copy specs |
|---|---|---|---|---|---|---|---|---|---|
| 20x8.5 | 30 | 6x139.7 | 78.1 | 37.5*22.5 depth 20 | 1000 | 14.7 | Nissan Patrol | 7 | |
| 21x9 | 30 | 6x139.7 | 78.1 | 37.5*22.5 depth 20 | 1000 | 16.2 | 8 | ||
| 22x9 | 30 | 6x139.7 | 78.1 | 37.5*22.5 depth 20 | 1000 | 17.5 | 12 |
What these numbers mean
- Size (D x J)
- Diameter in inches, then rim width in inches: 20x8.5 is a 20 inch wheel with a 8.5 inch wide rim. The J after a width, as in 8.5J, names the rim flange profile.
- Offset (ET)
- The distance in mm from the wheel's centerline to its mounting face. WD0263 comes in ET 30; a lower ET sits the wheel further out.
- Bolt pattern (PCD)
- The number of bolts and the diameter in mm of the circle they sit on: 6x139.7 is 6 bolts on a 139.7 mm circle. It must match the vehicle.
- Center bore (CB)
- The central hole that sits over the vehicle's hub: 78.1 mm for WD0263. A bore larger than the hub needs centering rings.
Fits the same bolt pattern and size
Same PCD, wheel diameter and a compatible center bore.
Similar finish and range
Same collection, with a matching finish or vehicle brand.
Similar design
Wheels that look alike, from the same collection. Check the bolt pattern before you order.
